Datalogic Gryphon – die vielseitige POS- und Service-Scannerfamilie
Die Gryphon-Serie steht für komfortables, schnelles Scannen und erstklassige Ergonomie im täglichen Betrieb. Ob klassischer Kassenplatz, Click-&-Collect, Kundenservice, leichte Lageraufgaben oder Wareneingang – Gryphon bietet vom 1D-Einstiegsgerät bis zum leistungsstarken 2D-Scanner mit Bluetooth und drahtloser Ladetechnik die passende Lösung.
Typisch für Datalogic: Green Spot (optische Lesebestätigung direkt auf dem Code), Motion-Sensing für den Wechsel zwischen Hand- und Präsentationsmodus und robuste Gehäuse.
Barcodescanner aus der Datalogic Gryphon Serie kaufen
Bluetooth scanner, 2D, imager, green spot, 3GL, Bluetooth, IP52, incl.: battery, 3250mAh, order separately: charging/transfer station, color: black
Bluetooth scanner, healthcare, 2D, imager, green spot, 3GL, disinfectable housing, Bluetooth, IP52, incl.: cable (USB, straight, 2 m, white), charging/transfer station, battery, 3250 mAh, color: white
Bluetooth scanner, 2D, imager, green spot, 3GL, Bluetooth, IP52, incl.: cable (USB, straight, 2 m, black), charging/transfer station, battery, 3250 mAh, color: black
Bluetooth scanner, 2D, imager (high density), green spot, 3GL, Bluetooth, IP52, incl.: battery, 3250mAh, order separately: charging/transfer station, color: black
Handheld scanner, 2D, imager (illumination: white), green spot, 3GL, USB, IP52, incl.: cable (USB, straight, 2 m, black), stand, color: black
Built-in scanner, 2D, imager (1 MP, wide angle, exposure: white), micro-USB, IP54, black
Handheld scanner, healthcare, 2D, imager (high density, exposure: white), green spot, 3GL, antibacterial housing, USB, IP52, incl.: cable (USB, straight, 2 m, white), color: white
Datalogic Gryphon I GM4500 - High Density (HD) - Barcode scanner - portable - 2D imager - decodes - RF (433 MHz)
The Gryphon 4500 series is the premium range in Datalogic's universal scanner segment. Its ergonomic design guarantees maximum user-friendliness. An innovative Mexapixel sensor with white illumination also ensures strong reading performance.Datalogic Gryphon I GD4590 - Barcode scanner - Handheld device - 2D imager - Decodes - Keyboard wedge, RS-232, USB
The Gryphon 4500 series was developed with people in mind and impresses with its elegant design, unmatched ergonomics, and advanced sensor for outstanding performance.Datalogic Gryphon I GBT4500 - Kit - Barcode scanner - portable - 2D imager - decodes - Bluetooth 4.0
Datalogic Gryphon I GM4500-HC - High Density (HD) - USB Kit - Barcode Scanner - Portable - 2D Imager - Decodes - RF (433 MHz)
The Gryphon 4500 series is the premium range in Datalogic's universal scanner segment. Its ergonomic design guarantees maximum user-friendliness. An innovative Mexapixel sensor with white illumination also ensures strong reading performance.Datalogic Gryphon I GD4520 - High Density (HD) - Kit - Barcode scanner - 2D imager - decodes - USB
The Gryphon 4500 series is the premium range in Datalogic's universal scanner segment. Its ergonomic design guarantees maximum user-friendliness. An innovative Mexapixel sensor with white illumination also ensures strong reading performance.Datalogic Gryphon I GD4520 - Kit - Barcode scanner - 2D imager - decodes - USB
The Gryphon 4500 series is the premium range in Datalogic's universal scanner segment. Its ergonomic design guarantees maximum user-friendliness. An innovative Mexapixel sensor with white illumination also ensures strong reading performance.Datalogic Gryphon I GD4520 - High Density (HD) - Kit - Barcode scanner - Handheld device - 2D imager - decodes - USB
The Datalogic Gryphon GFS4520 barcode scanner is a powerful tool designed to meet the diverse needs of modern businesses. With its ability to accurately read a wide range of barcode types, including everything from Australian Post to QR codes and Data Matrix, it offers versatility. The high frame rate of 60 frames/sec. combined with a sensor resolution of 1280 x 800 ensures fast and accurate scanning, making it the ideal choice for high-volume scanning environments.An important feature of the Gryphon GFS4520 is its durability: its IP54 rating provides protection against dust and water, ensuring that it can be used even in harsh conditions. In addition, it complies with important environmental and safety standards such as China RoHS, EU RoHS, and IEC 62471, making it a responsible choice for companies looking to minimize their environmental footprint. Whether in retail, logistics, or healthcare, the Gryphon GFS4520 is designed to improve operational efficiency and reliability.Datalogic Gryphon GFS4520 - Barcode scanner - Desktop device - 2D imager - 60 images/sec - USB
The Datalogic Gryphon GFS4520 barcode scanner is a powerful tool designed to meet the diverse needs of modern businesses. With its ability to accurately read a wide range of barcode types, including everything from Australian Post to QR codes and Data Matrix, it offers versatility. The high frame rate of 60 frames/sec. combined with a sensor resolution of 1280 x 800 ensures fast and accurate scanning, making it the ideal choice for high-volume scanning environments.An important feature of the Gryphon GFS4520 is its durability: its IP54 rating provides protection against dust and water, ensuring that it can be used even in harsh conditions. In addition, it complies with important environmental and safety standards such as China RoHS, EU RoHS, and IEC 62471, making it a responsible choice for companies looking to minimize their environmental footprint. Whether in retail, logistics, or healthcare, the Gryphon GFS4520 is designed to improve operational efficiency and reliability.Datalogic Gryphon GFS4520 - Barcode scanner - Desktop device - 2D imager - 60 images/sec - USB
The Datalogic Gryphon GFE4590-RED barcode scanner is a device designed to meet the demands of fast-paced work environments. With its advanced 2D imager, it can quickly and accurately read a wide range of barcode types, from traditional to modern, including QR codes and Digimarc barcodes. Its rugged design, with a drop rating of 1.5 m onto concrete and an IP54 rating, ensures that it can withstand the rigors of daily use in a variety of environments. The high frame rate of 60 frames/sec, combined with a maximum working distance of 82 cm and a large field of view, make the scanner the ideal choice for retail, warehousing, and logistics. In addition, the red LED light source and high sensor resolution ensure clear visibility and accurate scanning, increasing operational efficiency. Choose the Datalogic Gryphon GFE4590-RED for a reliable scanning solution.Datalogic Gryphon GFE4590-RED - Barcode scanner - integrated - 2D imager - 60 frames/sec - decodes - USB, RS-232
Discover the Datalogic Gryphon GFS4550, a barcode scanner designed to meet the diverse needs of modern businesses. This device has an impressive ability to decode a wide range of barcode types, from traditional ones such as UPC-A and EAN/JAN to formats such as QR codes and Data Matrix. Its rugged design offers protection against drops and IP54 protection, ensuring it can withstand the demands of busy work environments.The GFS4550 features a high frame rate and excellent sensor resolution for fast and accurate scanning. It also features red LED illumination and a wide scan field to meet a variety of operational requirements. Thanks to its wired connectivity and the included serial cable, this scanner integrates seamlessly into existing systems and offers reliable data transfer. The user-friendly feedback system with LED indicators and beeps ensures efficient operation, as successful scans are confirmed immediately. Choose the Datalogic Gryphon GFS4550 for a versatile, durable, and powerful scanning solution.Datalogic Gryphon GFS4550 - Barcode scanner - Desktop device - 2D imager - 60 images/sec - decodes - RS-232
Datalogic Gryphon I GM4200 - Barcode scanner - portable - decodes - RF (433 MHz)
Datalogic Gryphon I GBT4200 - USB Kit - Barcode scanner - portable - Linear imager - 400 scans/sec. - decodes - Bluetooth 4.0
Datalogic Gryphon I GM4200 - Barcode scanner - portable - decodes - RF (433 MHz)
Datalogic Gryphon I GM4200 - Barcode scanner - portable - decodes - RF (433 MHz)
The Gryphon 4500 series is the premium range in Datalogic's universal scanner segment. Its ergonomic design guarantees maximum user-friendliness. An innovative Mexapixel sensor with white illumination also ensures powerful reading performance.Datalogic Gryphon I GD4520 - Kit - Barcode scanner - Handheld device - 2D imager - Decodes - USB
The Gryphon 4500 series is the premium range in Datalogic's universal scanner segment. Its ergonomic design guarantees maximum user-friendliness. An innovative Mexapixel sensor with white illumination also ensures strong reading performance.Datalogic Gryphon I GD4590 - Barcode scanner - Handheld device - 2D imager - Decodes - Keyboard wedge, RS-232, USB
The Gryphon 4500 series is the premium range in Datalogic's universal scanner segment. Its ergonomic design guarantees maximum user-friendliness. An innovative Mexapixel sensor with white illumination also ensures strong reading performance.Datalogic Gryphon I GD4520-HC - Kit - Barcode scanner - Handheld device - 2D imager - Decodes - USB
Kurzberatung – welches Gryphon-Modell passt?
-
1D, budgetfreundlich & robust (Kabel oder Funk):
-
Gryphon I GD4220 – kabelgebunden, sehr gutes Preis-/Leistungsverhältnis am POS.
-
Gryphon I GM4200 – kabellos (STAR-Funk), ideal, wenn Bluetooth nicht gewünscht ist oder hohe Funkstabilität im Store zählt.
-
Gryphon I GD4290 – kabelgebundene 1D-Variante mit erweiterter Performance (z. B. Reichweite/Präsentationsbetrieb).
-
-
2D, zukunftssicher (QR, PDF, Datamatrix) – kabelgebunden vs. Bluetooth:
-
Gryphon I GD4520 – 2D-Allrounder für POS & Service, stark bei Codes auf Displays.
-
Gryphon I GBT4500 – 2D + Bluetooth mit drahtloser Ladetechnik (WLC); maximale Bewegungsfreiheit am Kassenplatz oder im Store.
-
Gryphon I GD4590 – High-Performance-2D für hohes Scanaufkommen und schwierige/kleine Codes.
-
Datalogic Gryphon – Modellvergleich & Eckdaten
| Modell | Scan-Technik | Konnektivität | Komfort & Ergonomie | Ideal für | Besonderheiten |
|---|---|---|---|---|---|
|
Gryphon I GD4220 1D, kabelgebunden |
1D Linear-Imager | USB/KB/RS-232 (je nach Ausführung) | Green Spot Präsentationsmodus | Kassenplatz, Service-Counter, Standard-POS | Einstiegs-Preis, zuverlässige 1D-Performance |
|
Gryphon I GM4200 1D, kabellos (STAR-Funk) |
1D Linear-Imager | Funk (433 MHz) + Cradle | Kabellos Green Spot | Mobiles POS, Regalpflege, größere Theken | Bluetooth-Alternative; stabile Filial-Funkstrecke |
|
Gryphon I GD4290 1D, kabelgebunden (Performance) |
1D Linear-Imager | USB/KB/RS-232 | Green Spot Präsentationsmodus | POS mit größerem Arbeitsabstand/Tempo | Erweiterte 1D-Leistung (Reichweite/Tempo) |
|
Gryphon I GD4520 2D, kabelgebunden |
1D/2D Area-Imager | USB/KB/RS-232 | Green Spot Screens/QR | POS mit QR-/Mobile-Coupons, Versandlabels | Zukunftssicher (2D), stark bei Bildschirmen |
|
Gryphon I GBT4500 2D, Bluetooth + WLC |
1D/2D Area-Imager | Bluetooth + Lade/Kommunikations-Cradle | Kabellos Wireless Charging | Mobiles POS, Click-&-Collect, Spitzenzeiten | Drahtlose Ladetechnik (weniger Kontaktverschleiß) |
|
Gryphon I GD4590 2D, High-Performance |
1D/2D Area-Imager (High-Perf.) | USB/KB/RS-232 | Green Spot Schnelle Decodes | Hohes Aufkommen, kleine/schlechte Codes | Sehr hohe Toleranz & Geschwindigkeit |
Einsatzszenarien – so treffen Sie die beste Wahl
-
Kassenplatz, Ticket-/Service-Counter: GD4220 (1D) oder GD4520 (2D).
-
Mobiles POS, Click-&-Collect, Regalpflege: GBT4500 (2D + Bluetooth, kabellos, WLC).
-
Filialen mit Funkanforderung ohne Bluetooth: GM4200 (1D, STAR-Funk).
-
Hohes Aufkommen, teils schwierige Etiketten, kleine Codes: GD4590 (2D High-Performance).
-
Budget-/Standard-POS mit 1D-Etiketten: GD4220 oder GD4290 (je nach gewünschter Performance/Arbeitsabstand).
Welcher Gryphon passt zu Ihrem Zweck?
| Szenario | Empfohlenes Modell | Warum? |
|---|---|---|
| Kassenplatz, Standard-POS mit 1D-Etiketten | GD4220 | Günstig, zuverlässig, sehr gute 1D-Leistung am POS. |
| POS mit größerem Abstand/Tempo (nur 1D) | GD4290 | Erweiterte 1D-Performance für schnellere/weitere Scans. |
| Mobiles POS/Regalpflege ohne Bluetooth | GM4200 | Kabellos via STAR-Funk – stabile Funkstrecke, Cradle-Betrieb. |
| QR-/Mobile-Coupons, 2D-Codes, Screens | GD4520 | 2D-Allrounder – stark auf Displays, zukunftssicher. |
| Kabellose Freiheit, Click-&-Collect, Stoßzeiten | GBT4500 | Bluetooth + Wireless Charging – weniger Ausfall durch Kontakte. |
| Hohes Aufkommen, schwierige/kleine Codes | GD4590 | High-Performance-2D mit schneller Decode-Rate & hoher Toleranz. |
Warum bei auto-iD247.com kaufen?
Wir beraten modellgenau nach Branche, Scanvolumen, Etikettentypen, Kassen-/ERP-Anbindung und Budget. Auf Wunsch mit Preset-Konfiguration (Töne, Symbologien, Schnittstelle) und passendem Zubehör (Cradles, Ständer, Kabel, Ersatzakkus). So erhälten Sie genau den Gryphon, der zu Ihrem Geschäft passt – ohne Kompromisse.
